Description
| Flow Rate | 8 gpm |
| Pressure | 4000 psi |
| Temperature Rise Over Incoming Water | 100 ºF |
| Engine Type | Honda GX800 EFI Electric Start Belt Drive |
| Fuel Source |
Kerosene, #1, #2 Diesel
|
| Fuel Consumption | 3.0 gal/h |
| Fuel Tank Capacity | 7 gal |
| Gas Tank Capacity | 7 gal |
| Burner Auto Ignition Voltage | 12 v |
| BTU Rating | 570000 Btu |
| Pump Style | Oil Bath Crankcase|Triplex Ceramic Plunger |
| Coil Type | Horizontal Schedule 80 |
| Coil Construction Type | Hydro insulated cold water wrap |
| Coil Length | 158 ft |
| Coil Diameter | 3/4 in |
| Float Tank Construction Material | Stainless Steel |
| Chemical Features |
High Pressure|Precise Metered
|
| Manufacturing Notes |
Batteries not included. Optional wheel kits available. All 12 volt burner units available with optional high limit control.
|
| Hose Length | 50 in |
| Hose Diameter | 1/2 in |
| Length | 48 in |
| Width Portable | 31.25 in |
| Width Stationary | 22.25 in |
| Height | 41 in |
| Weight | 800 lbs |
